Electric Rock Loader

Electric Rock Loader ;

Basic Info.

Model NO.	Z-30AW
HS Code	8428903900
Production Capacity	100000/Days

Product Description

Machine PurposeZ-30AW-type non-rope electric rockloader is a lightweight shipping machinery with single bucket, its purpose is to put rock or ore which collapse from blasting into mine truck to realize loading mechanization.It is suitable for a small section (2.5m × 2.5m), level or less than 8° tilt prospecting or roadway. The packaging material is very wide, such as granite, metal mining, general rock, sand, salt etc. The max diameter of the loaded rock is 500 mm, while the diameter of 200 ~ 300 mm, its efficiency is maximum. The machine is of wet and drip-proof, can be used in dry or wet places.The machine is non-explosion-proof. B,Main Technical Performance1,Loading capacity 0-60 m3/h2,Bucket volume 0.30 m33,Loading width 2.2 m4,Running speed 0.71m/s5,Rail distance 600 mm6,Discharge height 1350 mm 7,Discharge distance 340 mm 8,Bucket maximum raise height 2240 mm9,Machine dimension( length × width× height) 2620×1300×1545mm10,Machine Weight 4600kg
